Cinema Chroma 12V RGBATD Flex LED Ribbon 252LEDs Per Meter
Cinema Chroma 12V RGBATD Flex LED Ribbon 252LEDs Per Meter
Cinema Chroma 12V RGBATD Flex LED Ribbon 252LEDs Per Meter
Cinema Chroma 12V RGBATD Flex LED Ribbon 252LEDs Per Meter
Cinema Chroma 12V RGBATD Flex LED Ribbon 252LEDs Per Meter
Cinema Chroma 12V RGBATD Flex LED Ribbon 252LEDs Per Meter
Cinema Chroma 12V RGBATD Flex LED Ribbon 252LEDs Per Meter
Cinema Chroma 12V RGBATD Flex LED Ribbon 252LEDs Per Meter
● High density with 252LEDs per meter;
● DC12V with 15mm width PCB Design;
● High CRI value for Tungsteh(Warm white) & Daylight(Cool white), Ra>95;
● High TLCI Value for Tungsteh(Warm white) & Daylight(Cool white),TLCI>97;
● High Power with 44.3W/M;
● High lumen output,2705lm/m max.
Description
Technical Parameters
Cinema Chroma 12V RGBATD Flex LED Ribbon 252LEDs per Meter Description
High CRI Chroma RGBACCT LED Flexible Ribbon double rows 252leds/m 12V version is the most popular products in our Chroms strip series, due to it's reailble, even light distribution,
designed with DC24V double rows with checkboard layout, by using high brightness 5050 RGBA 4-in-1 SMD combined with cinema-quality 2835 SMD, with high brightness, high CRI value over 95, and R1-R15 all over 90, high TLCI of 95+. With amber color conbined compare with RGBCCT series, which can achieve more rich and colorful effect by using a DMX or other 6 channels controller.
Cinema Chroma 12V RGBATD Flex LED Ribbon 252LEDs per Meter main Features
● Working with DC 12v;
● 15mm width PCB Design with double rows layout and checkboard distribution;
● 5050 RGBA 4-IN-1 LED and 2835 SMD as Light sources;
● High Density with 252leds/m(RGBA/T/D each 84pcs);
● Wide CCT range Selectable: Tungsten from 2000K-3500K, Daylight from 5000K-10000K;
● High Wattage and High Brightness;
● UL/CUL Listed with file No. E495503, CE certificated and RoHS Compliant.
Certifications for Cinema Chroma 12V RGBATD Flex LED Ribbon 252LEDs per Meter
R/G/B/A Spectrum & Wavelength
CRI, Spectrum & Wavelength for tungsten & Daylight CCT Range from 2000K-10000K, standard CCT for Tungsten 2800K and 3200K, Daylight 5600K and 6500K, flame color and blue daylight can be customized
Standard Tungsten Color 2800K & 3200K
Standard Daylight Color 5600K & 6500K
Customized Flame Color 2000K & 2200K
Customized Blue Daylight Color 10000K
product details
For our 5050 RGBA+2835 CCT LED Ribbon series we offer DC12V 252LEDS/m version, the whole series use 18AWG 7pin bare wire with low voltage drop, and also thicker PCB of 3oz copper layer ensure the good heat radiation and also keep low voltage drop. For backadhesive, we use 3M 9080HL as standard, and also for other backadhesive like 300LE tape, 3M VHB or TESA tape etc.
Products Dimensions
Why High CRI?
Why Choose US?
13 Years Experience in LED Industry
We have over 13 years experience in LED industry and have a team working in LED industry for many years.
Strict Quality Control
We have a strict quality control system according to ISO, and we have strict quality control process during all production.
High Quality LED Strip Manufacturer
We choose all best materials include 3oz or even 4 oz copper for our PCB and all high quality led components.
Fast Delivery
We have saftey stocked PCB to ensure the fast delivery, for sampels around 7 days, and for mass production around 15 days.
Self R & D
We have professional team, who have a rich experience in high end strip products, and we have a series of self R&D products to meet your different requirement.
OEM & ODM Services
Besides our self R&D products, we also offer OEM and ODM for our customer all world wide, for any LED strip related products, give us your idea, we will offer best products for you!
Our Factory
R&D
quality Control
Our Exhibitions
Our Equipments
Cinema Chroma 12V RGBATD Flex LED Ribbon 252LEDs per Meter Applications
For the high CRI RGBACCT Flexible LED Strips, which are designed to be used for film, television, and wherever a desire for high quality lighting is required. With richable color available and they are fantastic in tight spaces and for shooting on location.Extremely vrsatile, light-wight, color-correct, and economical make these RGBACCT color flexible LED Strips a hit with cinematographers and DOPs alike. Thus for the whole strips series are suitable and widely usde for film, TV, studio, photographic studio, news studio, liveing shows, commercial shooting etc. and also a best choice for high-end projects.
Other Best Selling Chroma Product Recommend
2835 RGBCCT Flex Ribbon 252leds/m Single Row
5050RGB+2835 CCT Flex Ribbon 252leds/m Double Row
RGBCCT COB Flex Ribbon 24V
High Density 2835 RGB 240leds/m, DC24V
5050RGBA+2835CCT 252leds/m Double Rows DC24V
5050RGBA+2835CCT 288leds/m Double Rows DC12V
5050RGBA+2835CCT 576leds/m Four Rows DC24V
RGBW COB Flex LED Ribbon 24V
Hot Tags: cinema chroma 12v rgbatd flex led ribbon 252leds per meter, China, manufacturers, suppliers, factory, customized
Products Technical Parameters
| Product Code | GLUA12CV015L0203FH03W252C3 |
| Part Number | GLU-S6L0203FH252-12V |
| LED Type | 5050 RGBA 4-in-1 SMD +2835 SMD |
| LED Qty. | 252PCS(RGBA/T/D each 84pcs) |
| CRI Whites | 95+ |
| R1-R15 Whites | 90+ |
| TLCI Whites | 95+ |
| Copper Thickness | 3oz(1oz+2oz) |
| PCB Width | 15mm(0.59 in.) |
| PCB Color | White(Others can be customized) |
| Opearation Voltage | DC12V Constant Voltage(DC8-13V) |
| Current per Meter | 2.7A(R/G/B/A 0.5A, T/D 0.84A) |
| Power per Meter | 44.3W(R/G/B/A 6.05W, T/D 10.08W) |
| Lumen per Meter | R 170lm/G 480lm/B 120lm/A 165lm / T 830lm/D 940lm |
| IP Rating | IP20 |
| Cutting Length | 35.71mm(1.41in.) |
| Cuttable Segment per Meter | 28 |
| LEDs per Cutting Segment | 9PCS(5050RGBA/2835 T/2835 D each 3pcs) |
| Total LEDs per Roll | 378pcs(UL/CUL Standard),1260pcs(CE Standard) |
| LED Specing | 11.9mm(0.47in.) |
| Strip Overall Thickness | 2mm(0.079in.) |
| Packing Length |
1500mm(59.06in./4.92ft) UL/CUL Standard 5000mm(196.85in./16.4ft)/CT Standard |
| Number of Tracks | 7 |
| View Angle | 120 degree |
| Max. Recommended Length | 5meter(16.4ft.) |
| Connections | 7 pin bare wire |
| Installation | 3M 9080HL, 3M 300LE or others optional |
Note: 1. The tolerance of lumen fux and power is ±10% due to difference for test equipment.
2. The parameters may change without prior notice.
