RGBW COB LED Strip

High CRI RGBW COB Flexible Strip
● High density with 952chips per meter;
● DC24V 12mm width PCB Design;
● High CRI value for Tungsteh(Warm white) or Daylight(Cool white), Ra>95;
● High TLCI Value for Tungsteh(Warm white) or Daylight(Cool white),TLCI>97;
● Continuous light, dot-free;
● High lumen outout, 24W/M max.
Send Inquiry

Description

Technical Parameters



RGBW



product key informations
RGBW-COB-LED-STRIP
01.

rGBW COB LED STRIP

Our RGBW COB LED Strip is a new series light strip creates a virtually seamless, diffused, soft output without the ability to see individual light points unlik the traditional led strips. The innovative RGBW COB LED Strip design shows minimal light dots making the RGBW COB an idea design for the place where a soft light and no dot effect is required. The RGBW COB only 12mm width makes the strip can be installed in any narrow place.

The RGBW COB LED Strip use chip-on-board(COB) type design arranged the Red, Green, Blue, Tungsten and Daylight in a narrow 12mm PCB,

Short Cuttable with 29.41mm in DC24V and at the same time providing convenient solder pads on top of the PCB.

02.

High CRI Solutions For our RGBW COB Strip

Our high CRI RGBW COB LED Strip adopting high-performance small packed led inner and top quality silicone specially for COB strip, and special layout, make the RGBW COB LED Strip with high performance with high CRI for the tungsten part. With a Ra value for Tungsten over 96, TLCI value over 97.

RGBW COB LED STRIP-2
RGBW COB LED STRIP-5
03.

Short cuttable with 12mm width

The RGBW COB LED Strip is designed with only 12mm width, which can be used for any narrow place, and with short cutting with cut point 29.41mm wihch is flexible for using. For our RGBW COB LED Strip is UL LISTED for the U.S.A and CUL LISTED for Canada, we offer 4meter/reel for UL standard and 5meter/reel for CE standard.

04.

RGBW COB LED Strip applications

The RGB CCT COB flexible strip is an idea product, where a continous light effect is needed. It's dot free effect and riched color and also easy using, make it a best choice for home use, entertainment venues etc.

Due to the high CRI for tungsten(warm white) and daylight(white) and controllable by high frequency DMX dimmer makes the strip also a perfered product for the film, studioo and photography industry.

RGBW COB LED Strip-4

Why Choose Us

13 Years experience
 Over 13 Years experience
High Quality LED Strip
top quality LED strip products Manufacturer
strict quality control
 strict qualty control proces
sefl RD
own professional R&D team
OEMODM
professional OEM and ODM serivices
FAST DELIVERY
 fast delivery wroldwide

Our Certificate





product-465-320
UL

UL/CUL File No. E495503

CE

CE Certification

ROHS

RoHS Compliant

Hot Tags: rgbw cob led strip, China, manufacturers, suppliers, factory, customized



 product parameters
Product name RGBW COB LED Strip
Product code GLUA24CV012L0000FQ07W952C3
Product model GLU-S4L0000FQ952-24V
LED Type COB
Chip Qty. 952chips/meter(Red,Green,Blue, Warm white each 238chips)
CCT RGB+Tungsten/Warm white(3100K)
CRI Whites 95+
Copper thickness 3oz(1oz+2oz)
PCB Width 12mm(0.47in.)
PCB Color White(Others can be customized)
Operating voltage DC24V Constant Voltage
Current/Meter Red 0.22A, Green 0.22A , Blue 0.22A, Tungsten(Warm white) 0.34A
Power/Meter Red 5.28W, Green 5.28W , Blue 5.28W, Tungsten(Warm white) 8.16W
Lumen/Meter Red 142lm, Green 550lm , Blue 95lm, Tungsten(Warm white) 580lm
IP Rating IP20
Cutting Length 29.41mm(1.16 in.)
Packing length 4meter(157.48in.) for UL/CUL Standard, 5meter(196.85in.) CE Standard
Numbers of tracks 5
View angle 180 degree
Max. recommended length 5meters
Connections 5 pin bare wire
Installation 3M 9080HL, 3M 300LE or others optional

Note: 1. The tolerance of lumen 􀇃fux and power is ±10% due to difference for test equipment.

               2. The parameters may change without prior notice.
