Rail Type 12 Channels CV DMX And RDM Decoder

GLU Lighting, established in 2011, is one of the leading rail type 12 channels cv dmx and rdm decoder manufacturers and suppliers in China. Offering you customized service, we warmly welcome you to buy the high quality and beautiful rail type 12 channels cv dmx and rdm decoder from our factory.



● Comply with the DMX512 standard protocols.

● Digital numeric display, set DMX decode start address by buttons.

● RDM function can realize intercommunication between DMX master and decoder. For example, DMX decoder address can be set by DMX master console.

● 1/2/4 DMX channel output selectable.

● 16bit (65536 levels) /8bit (256 levels) grey level selectable.

● PWM frequency 500/1000/2000/4000/8000/16000Hz selectable.

● Logarithmic or linear dimming curve selectable.

● Stand-alone 12 channels RGB mode and 12 channel dimmer mode selectable, which be controlled by buttons with built-in programs, instead of DMX signal.

                                                                                                      RGB STRIP×4

Note:

1. An DMX signal amplifier is needed if more than 32 decoders are connected, or use overlong signal line, signal amplification should not be more than 5 times continuously.

2. If the recoil effect occurs because of longer signal line or bad line quality, please try to connect 0.25W 90-120Ω terminal resistor at the end of each DMX Signal line.
