OEM 24V Ra97 CCT Dimmable 120 Led/m 2835 Led Strip With UL/ CE/ RoHS
Description
Technical Parameters
IP68 Ra>95& Ra>97 tough solid silicone high CRI 2835 led strip with 3 years warranty
Newest IP68 waterproof treatment, tough solid silicone glue jacket with integrated extruded waterproof end cap, anti-corrsion, crush-proof , ideal suitable for underwater application, led step light etc.
1. High CRI: Ra97/Ra95 , R1 - R 15 all value above 90.
2. 3 year warranty
3. CE, RoHS/ UL
4. 0.2W ultrabright 2835 SMD with Epistar chip as light source
5. Double layer PCB with 2 OZ Cu enables sufficient heat dissipation
6. Ra97 and Ra95 are available for your choice.
7. single color and bi color CCT adjustable version is available.
8. CCT available in 1800K, 2200K, 2400K, 2600k, 2800K, 3000k, 3200K, 3500k, 4000K, 4500k, 5500K, 6000K, 6500k etc.
Superhigh CRI Ra97, R1 - R 15 all value above 90.
High brightness & High CRI underwater IP68 solid silicone 2835 led Strip are available in 60 led/m,84 led/m, 120led/m , 180 leds/, 240 leds/m and 280 leds/m and double row 168led/m !
1. Great light source: Super 0.2W 2835 SMD LED strip light, top quality Epistar chip 2835 SMD LEDs with high lumen LEDs 22-24lm.
2. Double-faced soft FPC with thicker copper layer.
3. Flexible in length suitable for different applications.
4. Both white and copper PCB available
5. Different colors for choice for different applications: cold white, natural white, warm white for different
applications.
6. Environmental friendly: complied with CE and RoHS standard without harmful substance, such as lead or Mercury etc.
7. 3 Years warranty.
24V High CRI Ra97 corrosion-proof underwater 2835 Led Strip Technique Data
Absolute Maximum Rating at TA=25°C
|
Parameter |
Symbol |
Absolute Maximum Rating |
Unit |
|
Forward Current |
IF |
425 |
mA |
|
Forward Voltage |
VF |
DC24V |
V |
|
Electrostatic discharge |
ESD |
400 |
V |
|
Operating Temperature |
Topr |
-25~+60 |
°C |
|
Storage Temperature |
Tstg |
-40~+80 |
°C |
Electrical / Optical Characteristics at TA=25°C
|
Part No. |
Color |
CCT/WLD |
Lumen Flux |
Current |
Power |
View Angle |
|
FMN-W-60 |
White |
6000-7000K |
1235lm |
0.425A |
10.2W |
120° |
|
FMN-WW-60 |
Warm White |
2800-3200k |
1120lm |
Featured products:
1. 5050 RGBW&RGBA 4 in 1 Led Strip
2. High brightness 3014 Side view Led strip/ 020 side view RGB in 1 Led Strip
3. Ra97 Ra95 2835/5630/3014/3528 Led strip
4. Ra97/Ra95 2835/3014/5630 bi color led strip
5. High power high cri flexible 24 x 50cm 2835 led panel light
6. High uniformity neon 2835/5050 led flexible led strip.
GLU Light 2017 hot sale led strips.
Glu Light factory:
Glu Light Led Strip in burning test:
Fully product inspection to make sure each product is perfect before shipment.
Warmly welcome trying our sample to start.
Welcome you to visit our factory at any time!
Any further questions,pls feel free to contact us!
