Meanwell Power Supply HLG-120H Series Main Features
● Constant Voltage + Constant Current mode output ;
● Metal housing with class I design;
●Built-in active PFC function;
●Class 2 power unit;
●IP67 / IP65 rating for indoor or outdoor installations;
●Function options: output adjustable via potentiometer;
3 in 1 dimming; Timer dimming;
●Typical lifetime > 62000 hours;
● 7 Years warranty.
HLG-120H series is a 120W AC/DC LED driver featuring the dual mode constant voltage and constant current output. HLG-120H operates from 90 ~ 305VAC and offers models with different rated voltage ranging between 12V and 54V. Thanks to the high efficiency up to 93%, with the fanless design, the entire series able to operate for -40°C ~ +80°C case temperature under free air convection. The design of metal housing and IP67/IP65 ingress protection level allows this series to fit both indoor and outdoor applications. HLG- 120H is equipped with various function options, such as dimming methodologies, so as to provide the optimal design flexibility for LED lighting system.
Meanwell HLG-120H Series
Dimensions
★ For other information about detailed operation pls refer to the user's manual or consult our sales.
Hot Tags: meanwell power supply hlg-120h series, China, manufacturers, suppliers, factory, customized
Technical Parameters
| Product |  |
 |
 |
| Model Number | HLG-120H-12A | HLG-120H-24A | HLG-120H-48A |
| Output DC Voltage | 12V | 24V | 48V |
| Output Current | 10A | 5A | 2.5A |
| Output Power | 120W | 120W | 120W |
|
Output DC Voltage Adj. Range |
10.8~13.5V | 22~27V | 43 ~ 53V |
|
Output Current Adj. Range |
5 ~10A | 2.5 ~ 5A | 1.2 ~2. 5A |
| Output DC Voltage Tolorance | ±2.5% | ±1.0% | ±1.0% |
| Pipple & Noise | 150mVp-p | 150mVp-p | 200mVp-p |
| Input Voltage Range | 90 ~ 305VAC 127 ~ 431VDC | 90 ~ 305VAC 127 ~ 431VDC | 90 ~ 305VAC 127 ~ 431VDC |
| Frequency Range | 47 ~ 63Hz | 47 ~ 63Hz | 47 ~ 63Hz |
|
Power Factor (Typ.) (Full Range) |
PF≧0.98/115VAC, PF≧0.95/230VAC, PF≧0.93/277VAC |
PF≧0.98/115VAC, PF≧0.95/230VAC, PF≧0.93/277VAC |
PF≧0.98/115VAC, PF≧0.95/230VAC, PF≧0.93/277VAC |
| Efficiency | 92% | 93% | 93.5% |
| AC Current(Typ.) | 1.4A / 115VAC 0.6A / 230VAC 0.55A / 277VAC | 1.4A / 115VAC 0.6A / 230VAC 0.55A / 277VAC | 1.4A / 115VAC 0.6A / 230VAC 0.55A / 277VAC |
| Leakage Current | <0.75mA/277VAC | <0.75mA/277VAC | <0.75mA/277VAC |
| Protection |
Over Current, Short Current, Over Voltage, Over Temperature |
Over Current, Short Current, Over Voltage, Over Temperature |
Over Current, Short Current, Over Voltage, Over Temperature |
| Housing and Color | Fully enclosed aluminum housing, Sliver | Fully enclosed aluminum housing, Sliver | Fully enclosed aluminum housing, Sliver |
| Max. Housing Temp. | Tcase=+80℃ | Tcase=+80℃ | Tcase=+80℃ |
| Working Temp. | Tcase=-40℃~ +80℃ | Tcase=-40℃~ +80℃ | Tcase=-40℃~ +80℃ |
| AC Input type | Bare wire- Stripped & Tinned | Bare wire- Stripped & Tinned | Bare wire- Stripped & Tinned |
| Output Connector Type | Bare wire- Stripped & Tinned | Bare wire- Stripped & Tinned | Bare wire- Stripped & Tinned |
| Dimension | 220*68*38.8mm(L*W*H) | 220*68*38.8mm(L*W*H) | 220*68*38.8mm(L*W*H) |
| Packing | 1.12kg; 12pcs/14.4kg/0.8CUFT | 1.12kg; 12pcs/14.4kg/0.8CUFT | 1.12kg; 12pcs/14.4kg/0.8CUFT |
| Certification | UL/CUL/CE/TUV/CB | UL/CUL/CE/TUV/CB | UL/CUL/CE/TUV/CB |
*The above data are from Meanwell Spec. Datasheet.
