60W 24V AC-DC Meanwell Industrial Adaptor GS60A24-P1J
60W AC-DC Meanwell Industrial Adaptor GS40A24-P1J is a reliable and robust industrial power supply, Energy efficiency level V, with DC24V output, universal AC input 90 ~ 264VAC/ 127 ~ 370VDC, classⅠ power (with earth pin), with short circuit, overload,over voltage protection, which ensure the adaptor safe and reliable.
Send Inquiry
Description
Technical Parameters
60W AC-DC Meanwell Industrial Adaptor GS60A24-P1J
FEATURE
● Universal AC input / Full range
● No load power consumption<0.3W
● Energy efficiency Level V
● Comply with EISA 2007, NRCan, AU/NZ MEPS and EU ErP
● 3 pole AC inlet IEC320-C14
● ClassⅠpower (with earth pin)
● Protections: Short circuit / Overload / Over voltage
● Pass LPS
● Fully enclosed plastic case
● LED indicator for power on
● 2 years warranty
Recommended acccessory
SPECIFICATION
| Output voltage(V) | DC24V |
| Current(A) | 2.5A |
| Output power(W) | 60W |
| Agency Approvals | UL/CUL/TUV/GS/CCC/PSE/CB/FCC/CE |
| Size(mm/inches) | 125×50×31.5/4.9×1.9×1.2 |
| RIPPLE & NOISE (mVp-p) | 180mVp-p |
| Voltage tolerance | ±3.0% |
| Line regulation | ±1.0% |
| Load regulation | ±3.0% |
| Efficiency | 90% |
| Frequency range | 47~63Hz |
| Universal AC input | 90 ~ 264VAC 127 ~ 370VDC |
| Leakage current | 0.75mA/240Vac |
| Protections | Short circuit / Overload / Over voltage |
| AC Input | 3 pole IEC320-C14 |
| Housing | Fully enclosed plastic case |
| Indicator | LED indicator for power on |
| Standby power consumption | <0.3W |
| Output connector type | Cylindrical DC Female standard P1J |
| Output connector diameter | 2.1mm*5.5mm |
| Output polarity | Center positive |
| Working temperature | -30℃~+60℃ |
| Adaptor color | Black |
DIMENSION
