Description
Technical Parameters
GLU Lighting, established in 2011, is one of the leading high lumen r1-r15 above 90 ra97/95 2835 led strip with 120 leds/m 4 oz copper pcb manufacturers and suppliers in China. Offering you customized service, we warmly welcome you to buy the high quality and beautiful high lumen r1-r15 above 90 ra97/95 2835 led strip with 120 leds/m 4 oz copper pcb from our factory.
High lumen R1-R15 above 90 Ra97/95 2835 led strip with 120 leds/m 4 OZ Copper PCB
1. High CRI: Ra>97/Ra.95/Ra>90
2. 3 year warranty
3. CE, RoHS;
4. 0.2W ultrabright 2835 SMD with Epistar chip as light source
5. Double layer PCB with ± 2 OZ Cu enables sufficient heat dissipation.
High lumen R1-R15 above 90 Ra97/95 2835 led strip with 120 leds/m 4 OZ Copper PCB
1. Great light source: Super 0.2W 2835 SMD LED strip light, top quality Epistar chip 2835 SMD LEDs with high lumen LEDs 22-24lm.
2. Double-faced soft FPC with thicker copper layer.
3. Flexible in length suitable for different applications.
4. Both white and copper PCB available
5. Different colors for choice for different applications: cold white, natural white, warm white for different
applications.
6. Environmental friendly: complied with CE and RoHS standard without harmful substance, such as lead or Mercury etc.
7. 3 Years warranty.
High lumen R1-R15 above 90 Ra97/95 2835 led strip with 120 leds/m 4 OZ Copper PCB
Absolute Maximum Rating at TA=25°C
|
Parameter |
Symbol |
Absolute Maximum Rating |
Unit |
|
Forward Current |
IF |
425 |
mA |
|
Forward Voltage |
VF |
DC24V |
V |
|
Electrostatic discharge |
ESD |
400 |
V |
|
Operating Temperature |
Topr |
-25~+60 |
°C |
|
Storage Temperature |
Tstg |
-40~+80 |
°C |
Electrical / Optical Characteristics at TA=25°C
|
Part No. |
Color |
CCT/WLD |
Lumen Flux |
Current |
Power |
View Angle |
|
FMN-W-120 |
White |
6000-7000K |
2470lm |
0.85A |
20.4W |
120° |
|
FMN-WW-120 |
Warm White |
2800-3200k |
2240lm |
Note: 1. The lumen flux tolerance is ±5%;
2. The data above is based on 1 meters;
3. Test Temperature (Ambient temperature: TA=25°C)
High lumen R1-R15 above 90 Ra97/95 2835 led strip with 120 leds/m 4 OZ Copper PCB Application:
Our high CRI led strip are designed specifically for film, cinema, television, and anywhere high quality lighting is required.
--3528 smd led: 30leds/m, 60leds/m, 120leds/m, 180leds/m, 240leds/m(single row and double row);
--5050 smd led: 30leds/m, 60leds/m, 90leds/m, 120leds/m(Single row)
-2835 smd led: 30leds/m, 60leds/m, 84leds/m, 120leds/m (single row)Samsung 2835 led strip is available
--5630 smd led: 30leds/m, 60leds/m, 120leds/m (double row), Samsung 5630 is available
--RGBW led strip: 4 in one(60/72/84/96leds/m)
CCT adjustable led strip: 3528 120/240 leds/m, 5050 60leds/m, 2835 60/120 leds/m; 3014 240leds/m; 5630 60led/m and 120 leds/m. side view 3014 120leds/m bi color led strip and so on.
--digital strips WS2811,WS2812,SK6812,APA102 etc.
--2835/5050 Neon flexible led strips
2017 Featured led strip light
