24V high brightness High CRI 2835 Ra97 led flex strip, 180 leds/m, R1 to R15 all value above 90! High CRI: Ra97. CRI 95, R 1 to R 15 all value above 90, 3 year warranty CE, RoHS, UL. 1800K, 2200K, 2400K, 2600K, 2800K. 3200k, 3500k, 4000k, 4500k, 5000k, 5500k, 6000k, 6500k are available, Single color/ bi color Cct hybrid version is also available.

Send Inquiry

Description

Technical Parameters

24V high brightness High CRI 2835 Ra97 led flex strip, 180 leds/m, R1 to R15 all value above 90!

1. High CRI: Ra97. CRI 95, R 1 to R 15 all value above 90.

2. 3 year warranty CE, RoHS, UL.

3. 0.2W ultrabright 2835 SMD with Epistar chip as light source

4. Double layer PCB with 2 OZ Cu enables sufficient heat dissipation.

5. 1800K, 2200K, 2400K, 2600K, 2800K. 3200k, 3500k, 4000k, 4500k, 5000k, 5500k, 6000k, 6500k are available.

6. Single color/ bi color Cct hybrid version is also available.


High brightness & High CRI 2835 led Stripare available in 60led/m,84led/m/120led/m , 180 leds/m, 240 leds/m and 280 leds/m and double row 168led/m ! Led quantity, PCB width, voltage, power all can be customized.

China supplier 24V high brightness High CRI 2835 Ra97 2835 led flex strip Feature

1. Super 0.2W 2835 SMD LED strip light, top quality Epistar chip 2835 SMD LEDs with high lumen LEDs 22-24lm.
2. Double-faced soft FPC with thicker copper layer.
3. Flexible in length suitable for different applications.
4. Both white and copper PCB available
5. Different colors for choice for different applications: cold white, natural white, warm white for different
applications.
6. Environmental friendly: complied with CE and RoHS standard without harmful substance, such as lead or Mercury etc.

China manufacturer 24V high brightness High CRI 2835 Ra97 2835 led flex strip Technique Data

Absolute Maximum Rating at TA=25°C

Parameter	Symbol	Absolute Maximum Rating	Unit
Forward Current	IF	425	mA
Forward Voltage	VF	DC24V	V
Electrostatic discharge	ESD	400	V
Operating Temperature	Topr	-25~+60	°C
Storage Temperature	Tstg	-40~+80	°C

Electrical / Optical Characteristics at TA=25°C

Part No.	Color	CCT/WLD	Lumen Flux	Current	Power	View Angle
FMN-W-180	White	6000-7000K	1235lm	0.425A	10.2W	120°
FMN-WW-180	Warm White	2800-3200k	1120lm	0.425A	10.2W	120°

3 year warranty 24V high brightness High CRI 2835 Ra97 led flex strip 180 led/m Application

For Flexible Strips, they can be used as edge light, cove light, furniture light, sign light, backlighting for AdWords, lighting box etc., and widely used as decorative lighting for building outline, sidestep, exhibition stand, hotel, KTV, club etc. And also DIY Light for household use.
