Alibaba Express Hybrid Dual Colors Ra95 2835 Led Strip China Manufacturer

china 12v/24V Ra97 new hybrid dual color 2835 CCT led strip
china wholesale Ra97 two colors hybird 2835 cct led strip light
Hybrid two colors 2835 w/ww CCT adjustable led strip factory
Customized Ra97 w/ww 2835 led CCT changeable led strip
2017 new 12v Ra97 2835 hybrid CCT tunable led strip 120leds/m
Outdoor hybrid CCT dimmable 24V 2835 led strip china factory
Madeinchina high cri 12v dual color CCT 2835 led flex strip light
Alibaba express hybrid dual colors 2835 led strip china manufacturer
Custmoized CRI 97 2835 hybrid colors w/ww CCT dimmable led strip
Alibaba best sellers 24V new products 2835 CCT changeable led strip

Alibaba Express Hybrid Dual Colors Ra95 2835 Led Strip China Manufacturer

China high quality High cri Ra95 12V/24V W+WW CCT dimmable bi-color 2835 led strip 1. High CRI: Ra97 / Ra95 is available. 2. 3 year warranty,CE/ROHS.UL 3. Hybrid W/WW cct adjustable 2835 led strip . 4. 0.2W ultrabright 2835 SMD with Epistar chip as light source. 5. WW+W color temperature...

Send Inquiry

Download

Description

Technical Parameters

China high quality High cri Ra95 12V/24V W+WW CCT dimmable bi-color 2835 led strip

1. High CRI: Ra97 / Ra95 is available.
2. 3 year warranty,CE/ROHS.UL
3. Hybrid W/WW cct adjustable 2835 led strip .

4. 0.2W ultrabright 2835 SMD with Epistar chip as light source.

5. WW+W color temperature adjustable /Bi-color led strip.

6. Double layer PCB with ± 2 OZ Cu enables sufficient heat dissipation.

GLU Light High CRI Bi-color W+WW CCT adjustable led strip is available in 2835/5050/3014/3527 series:

product-471-348

High CRI Bi color CCT changable led strip shows an object true pure and vibrant color.

Here is a visual representation of the difference between low and high CRI :

China high quality High cri Ra95 12V/24V W+WW CCT dimmable bi-color 2835 led strip

1. Great light source: Super 0.2W 2835 SMD LED strip light, top quality Epistar chip 2835 SMD LEDs with high lumen LEDs 22-24lm.
2. Double-faced soft FPC with thicker copper layer.
3. Flexible in length suitable for different applications.
4. Both white and copper PCB available
5. Different colors for choice for different applications: cold white, natural white, warm white for different
applications.
6. Environmental friendly: complied with CE and RoHS standard without harmful substance, such as lead or Mercury.

7. 3 Years warranty.

120leds/m China high quality High cri Ra95 12V/24V W+WW CCT dimmable bi-color 2835 led strip Technique Data

Absolute Maximum Rating at TA=25°C

Parameter	Symbol	Absolute Maximum Rating	Unit
Forward Current	IF	425	mA
Forward Voltage	VF	DC24V	V
Electrostatic discharge	ESD	400	V
Operating Temperature	Topr	-25~+60	°C
Storage Temperature	Tstg	-40~+80	°C

Electrical / Optical Characteristics at TA=25°C

Part No.	Color	CCT/WLD	Lumen Flux	Current	Power	View Angle
FMN-W-60	White	6000-7000K	1235lm	0.425A	10.2W	120°
FMN-WW-60	Warm White	2800-3200k	1120lm	0.425A	10.2W	120°

Note: 1. The lumen flux tolerance is ±5%;

2. The data above is based on 1 meters;
3. Test Temperature (Ambient temperature: TA=25°C)

China high quality High cri Ra95 12V/24V W+WW CCT dimmable bi-color 2835 led strip Dimension

product-618-107

Notes:

1. All dimension units are millimeters.

2. All dimension tolerance is ± 0.5mm unless otherwise noted.

120leds/m China high quality High cri Ra95 12V/24V W+WW CCT dimmable bi-color 2835 led strip Connection Diagram

product-651-97

China high quality High cri Ra95 12V/24V W+WW CCT dimmable bi-color 2835 led strip

Application

High CRI full spectrum lighting can dramatically improve the appearance of objects, particularly in retail stores, shops, super-markets, museums, galleries and exhibits where red colors are prominent and presentation and appearance are critical. High CRI LED Lighting also has other applications in areas such as hospitals or textile industries where color differentiation is crucial in work performance. High CRI LEDs are ideal in locations where savings in energy consumption are desired, yet quality of light must be maintained.

product-601-399
